500W Power (Boost Mode: 950W)
Noiseless Passive Cooling
Image Based Lighting with 19 Pixel
Up to 107000lx at 1m
20° Native Beam Angle plus changeable Optics
High-output ready for Image Based Lighting and virtual production. An interactive lighting tool, fully integrated into current control environments.
A modular and versatile light that performs as a keylight, hardlight, punchlight, spacelight, or softlight.
-
Our engineering team built upon their previous success to create the full spectrum (RGBWW) 1800-10000K, 500W SUMOMAX. That can also be used in virtual production as an interactive lighting tool. Fully integrated into current control environments.
-
Passively cooled, fanless, with no noise.
-
With considerable advantages when it comes to building light boxes, light walls or other arrays. Fixtures can be arranged to create what one needs to suit the job. For enhanced lighting creativity cells within the structure can be controlled as a group or individually.
-
The unique one-click quick-release connecting system effectively allows multiple fixtures to safely and easily combine into powerful unlimited size arrays. It provides a secure screw-free interface to truss systems, standard junior pins and other grip hardware.
Safe for indoor or outdoor use, SUMOMAX is IP65 rated for maximum safety compliance regardless of conditions.
-
Thanks to its interchangeable optics module, beams may be enhanced and directed from narrow 20° native up to super wide 120°. For added illumination control, SUMOMAX works with an array of light shaping tools that transform it from a spacelight to softlight to a high intensity fixture.
-
Each fixture comes complete with an internal power supply, integrated touch screen, DMX, Art-Net and CRMX / Lumenradio. SUMOMAX is designed and engineered to seamlessly integrate with the existing SUMOLIGHT family.
-
Its streamlined, hexagonal profile measures:
582 x 504 x 200mm
22,9 x 19,8 x 7,9 inch
-
Apart from the common effects, due to its high pixelation, it is capable of being controlled and serves as an interactive source for light reflections. Integrated into virtual production workflows.
DISPLAY.
Control settings and presets from the touch display.
IMAGE BASED LIGHTING.
Purpose built for virtual production and IBL (Image Based Lighting).
Image Based Lighting ready with 19 pixels.
PIXEL MAPPING.
Available Beam Shaping Plates in the three variations of 30°, 60° and the Standard Diffuser Plate with magnet fit.
OPTICS
OPTICS.
Beam Shaping Plates
07-02-01-01-
07-02-01-01
1x Lens Plate for SUMOMAX; 30° beam angle.
07-02-01-02-
07-02-01-02
1x Lens Plate for SUMOMAX; 60° beam angle.
LIGHT SHAPING TOOLS.
07-07-02-07-
07-07-02-07
1x Space Light Skirts, 1x Target.
07-07-02-00-
07-07-02-00
1x Reflector, 1x Pyramid Baffle, 1x Space Light Skirts, 1x Magic Cloth Target 1x Bag.
07-02-02-01-
07-02-01-01
1x SUMOMAX Standard Diffuser Plate
07-02-03-03-ds-c01-07-02-03-t07-07-03-0307-02-02-03-
1x Reflector
-
1x Magic Cloth Pancake Lantern and Bag
-
1x Target for Space Light Skirt Classic
-
1x Softgrid for Reflector or Space Light Skirts
———
30° and 50° on request
01-02-03-03-bs-s01-02-03-03-ds-s-
1x Short Black Skirt Cover (1 x Half Panel).
-
1x Diffusion Skirt Short for Light Shaping Tools Kit.
-
1x Target for Reflector
-
1x Space Light Skirts
01-02-03-03-s07-02-03-03-tc
ACCESSORIES.
Mounts
07-03-00-0007-05-15-01-
1x Yoke-Mount for SUMOMAX
-
SUMOBEN. 1x 50mm Clamp Adapter for SUMOMAX Center Mount
07-05-01-00-
1x Hanger for SUMOMAX and SUMOSPACE+.
Cables & Cases
07-05-08-02-
1x Hardcase for 1 SUMOMAX and Accessories
-
powerCON TRUE1 TOP
Male to Female
SUMOSPACE+ Cable
-
Plug to powerCON TRUE1 TOP
7,5m
SUMOSPACE+ Compatible
99-04-7.5 EU AC Power Cord99-05-7.5 UK AC Power Cord
99-06-7.5 US AC Power Cord
99-10-1.599- 04/05/06 -7.5
1. Open the two screw handles on each side of the Yoke.
DEMOUNTING.
2. When both sides are unscrewed completely, pull both handles out until it clicks, then lose the yoke.
3. SUMOMAX can now be disconnected from the Yoke by pulling out vertically.
